2018 Dynamax Corp Isata 3 24FW
Not listed
Specifications
Length
24 ft 7 in
Dry weight
10,054 lbs
Sleeps
6 people
Slideouts
1
Unit features & options
- Mercedes-Benz® Sprinter Chassis
- 3.0L V6 Turbo Diesel Engine (188 HP and 325 FT/LB of Torque)
- 5-Speed Automatic Transmission with Overdrive
- 26.4 Gallon Fuel Tank
- 4.75 Gallon Diesel Exhaust Fluid Tank
- Trailer Hitch (5,000 Tow LB) with 7-Way Round Tow Connection
- 3-Year/36,000-Mile Roadside Assistance
- Upgraded Hellwig® Rear Sway Bar
- Electronic Stability Package
- Momentary Battery Booster Switch for Connecting Chassis and House Batteries
- Single 12V AGM Chassis Battery
- 220 AMP Alternator
- Fuel Filter with Water Separator
- LED Brake, Turn, and Backup Lights
- Aluminum Running Boards
- Front and Rear Tires: LT215/85 R16
- Single Front Wheels: Steel (5.5” x 16”)
- Dual Rear Wheels: Steel (5.5” x 16”)
- Valve Extensions
- 4.18 Rear Axle Ratio
- Spare Tire with Carrier Mounted to Frame
- Leatherette Driver and Passenger Seats with Swivel Bases and Pedestal Skirt
- Multi-Function Steering Wheel
- Instrument Cluster with Pixel-Matrix Display
Full specifications
AC BTU15000 btu
Available BedsQueen
Awning Info16' Electric with LED Lights
Axle Weight Front4410 lbs
Axle Weight Rear7720 lbs
Black Water Capacity32 gals
ChassisMercedes Benz Sprinter
Convection CookingYes
Cooktop Burners3
Electrical Service30 amp
Engine3.0L V6 Turbo Diesel
Ext Height11 ft 5 in
Ext Width7 ft 10 in
Exterior ColorCabernet, Cosmic Blue, Granite, Sunset, Khaki
Fresh Water Capacity35 gals
Fuel Capacity26.4 gals
Fuel TypeDiesel
Furnace BTU20000 btu
GVWR11030 lbs
Generator3.6KW Onan LP
Grey Water Capacity32 gals
Gross Combined Weight15250 lbs
Hitch Weight5000 lbs
Horsepower188 hp
Interior ColorSeashore, Pebble, Espresso
LP Tank Capacity20.3
Length24 ft 7 in
Number of Awnings1 ft
Refrigerator Size7 cu ft
Refrigerator TypeDouble Door
Shower TypeStandard
Sleeps3
Slides1
TV InfoLR 32" LED TV, BR 32" LED TV
Tire Size16
Torque325 ft-lb
Wheelbase170 in
Get more info
