Known for its Innovative styling, high-quality construction, compact but feature-rich floorplan, and convenient rear entry, the Chinook RV Maverick exemplifies superior craftsmanship, luxurious aesthetics, and practical functionality.

Ford Transit w/ AWD 4 Seasons Certified Solid Surface Countertops & Shower Premium Vinyl Padded Finish Ample Outside Storage

MAVERICK INFO

Dimensions

Exterior length - 24’ 5”

Exterior body width 88”

Exterior Height 10’ 6” w/ A/C

Interior Height 6’ 3”

Weights

GVWR – 11,000 lbs.

GCWR – 15.000 lbs.

Hitch Rating – 5000 lbs.

Tongue weight – 500 lbs.

Average Dry Weight – 9,780 lbs.

Holding Tank Size

Fresh – 30 Gallons

Gray – 24 Gallons

Black – 24 Gallons

Chassis Standards

• Ford Transit 350HD w/ AWD, 3.5L Eco Boost Twin-Turbo Gas Engine

• 10 Speed Transmission

• Navigation

• Safety features including blind spot detection, collision warning, lane keeping system & side-wind stabilization

• 31 Gallon Fuel Tank

• Preferred Equipment Package

• Tow Package

• Ford Aluminum Wheels

Maverick Package Standards

• Dometic Penguin II A/C

• Thermal Suppression System

• Timberline 1.0 Diesel Fired Hydronic Heat & On-Demand Hot Water System

• Xantrex 3000-Watt Inverter

• 400-Watt Merlin Solar Panel System w/ Solar Charger & Display

• Cummins Onan Gas Generator (STD on non-Lithium Models Only)

• AGM House Batteries 400 Amp Hours

• Echo Charger (Dual Battery Bank Charging, Charges House & Chassis Batteries)

• .055 Aluminum Roof & Sidewall Skins Bonded w/ Sika Adhesive

• Full Body Paint

• Double Pane Automotive Design Windows w/ Openable Section & Screens

• 2" x 4" Welded Steel Subfloor Assembly, Mounted on Rubber Isolator Pads

• 1 Piece Composite Subfloor & 1 Piece Composite Roof

• 4-point Leveling System

• Norcold / Thetford 6.2 cu ft Electric

• Induction Cooktop, Removable for Exterior Cooking

• Smart Plug - Detachable 30 Amp Power Cord

• Solid Surface Countertops, Shower, & Porcelain Toilet

• Soft Touch, Padded Vinyl Finishing

Maverick 360 Standards

• Maverick Package – Plus Below!!

• Electronic Systems Solution by Wellspring Components

• Expion 360 900 amp/hr. Lithium Battery System (10.8 KWH)

• High Output 2nd alternator w/ Gen Delete.

• Victron 3000-Watt Inverter w/ Charger & Cerbo Touch Screen Monitor

• 600-Watt Solar Panel System w/ Victron Solar Charger

• High output 2nd alternator w/ Gen Delete.

• Truma Aventa 13.5 BTU A/C with Built in Dehumidifier

• 4 Solar Panel Plug-in Ports in Exterior Side-Bay (480 Watts of Additional Solar Capability)

?

Note:

-The Maverick 360 Includes the Truma Aventa A/C IPO the Dometic A/C, & Victron components IPO of Xantrex & Merlin components. The Echo Charger is also removed & replaced with Battery Boost.

Options

• 4 Camera System

• Online Package (Winegard Starlink System)

• Optional 3rd Expion 450 amp/hr (360 Models Only)

• Cummins Onan 4,000-Watt Gas Generator (360 Models Only)

• Black Out Package (Black Wheels, A/T Tires, Black Handles)

• Cub Blind Spot Detection System

• Leveling Suspension Kit (2-inch Aluminum Front Lift Spacer)

• Altitude Suspension Kit (Rear 2-inch Aluminum Lift Spacer, Fox Rear Shocks, 2-Inch Front Lift Aluminum Spacer)

• Trail Hero Suspension Kit (Lower Control Arms, Progressive Leaf Springs, King 2.5 Coil Over Shock Kit & King 2.5 Rear Shocks)

Exterior Colors

-By Paint Scheme

Interior Colors

-Maple

-Walnut Chiffon

-Nizza

-Cortana Beige

Floorplans<br
