2026 Forest River Surveyor Legend 204MKLE

NewTravel trailer|Stock #NTT5527|Located at United R.V. Center in Haltom City, TX
$34,977$47,980
Save $13,003

204MKLE: The Legend of Versatility

The "MKLE" stands for Murphy bed / Kitchen / Luxury Edition, a layout designed to provide a massive living area during the day and a residential sleeping space at night.

Signature Living & Interior Highlights

  • Versatile Murphy Bed System: The star of the show. During the day, you have a comfortable sofa for lounging; at night, a 60" x 80" residential queen bed folds down over the sofa in seconds, with no "fold lines" like traditional hide-a-beds.

  • Massive Counter Space: Because the kitchen is located along the rear wall, the 204MKLE offers one of the largest prep areas in its class, complete with a deep stainless steel sink and a "hidden" trash can location.

  • Large Slide-Out Living: The single slide-out houses a U-shaped dinette (or optional theater seating), opening up the floor space significantly and providing a clear path to the bathroom even when the slide is in.

  • 10 cu. ft. 12V Refrigerator: A modern compressor-driven fridge that cools quickly and offers significantly more storage than a standard gas/electric unit.

  • Spacious Rear Bath: A full-width bathroom with a large walk-in shower, a linen closet, and a porcelain foot-flush toilet.

"Turn Key" Construction & Quality

  • Azdel Onboard® Composite: Built with Azdel sidewall panels that are 100% rot and mold proof. This material provides twice the insulation value of wood and significantly reduces the tow weight.

  • Goodyear® Endurance Tires: Standard with high-quality, American-made tires and a Tire Pressure Monitoring System (TPMS) for maximum safety on the highway.

  • Gel-Coated Fiberglass Front Cap: Features a large automotive-style windshield, letting in natural light while maintaining a sleek, durable front profile.

  • Central Vacuum System: Includes an interior sweep-port, making it easy to keep your living space clean after a day at the beach or on the trail.

Technology & Off-Grid Ready

  • 200W Solar Package: Includes a 200W roof-mounted panel and a 30-amp controller, with an inverter prep plug for easy expansion.

  • Tankless Water Heater: Provides an endless supply of hot water, controlled by an interior digital thermostat.

  • 12V Tank Heaters: Standard on all holding tanks to prevent freezing during cold-weather camping trips.

  • JBL Bluetooth Speaker: Features a rugged, portable JBL speaker that can be used inside or taken out to the campfire.

Specifications

Length

27 ft

Dry weight

5,493 lbs

Sleeps

5 people

Slideouts

1

Full specifications

Awning Length (FT/M)18'
Bathroom LocationRear
Bathroom MirrorYes
ClassTravel trailer
ConditionNEW
Dry Weight (LBS)5493 LBS
Exterior ColorWHITE
Kitchen LocationRear
Length (FT)27''
Length (FT/IN)27''
MakeFOREST RIVER
Master Bedroom LocationFront
Max Sleeping Count5
Microwave OvenYes
ModelSURVEYOR LEGEND
Number Of Awnings1 ft
Number Of Oven Burners3
Number Of Queen Size Beds1
Number Of Slideouts1
Refrigerator Size10 cu.ft
StatusAVAILABLE
Stock #NTT5527
Sub ClassRear Kitchen
Total Black Water Tank Capacity (GAL/L)30 GAL/L
Total Fresh Water Tank Capacity (GAL/L)40 GAL/L
Total Gray Water Tank Capacity (GAL/L)30 GAL/L
Trim204MKLE
Vin4X4TSVV21TL052927
Weight CategoryUnder 7500 Pounds
Year2026
