Not listed

The Colton RV & Marine Advantage

Specifications

Length

32 ft 11 in

Sleeps

6 people

Slideouts

3

Unit features & options

  • Automatic hydraulic leveling jacks
  • Ford F53 chassis
  • 7.3L V-8 335 HP engine with 468 ft.-lb. torque
  • 6-speed automatic TorqShift transmission with overdrive and tow haul mode
  • 210-amp alternator
  • Catalytic converter theft deterrent
  • G-rated highway tires - 235/80R22.5 (34B, 34G), 255/80R22.5 (36A, 36C)
  • Front and rear disc, 4-wheel anti-lock brakes
  • 5,000-lb. rear hitch receiver with dual connector and 7-pin plug
  • 12V chassis battery
  • 80-gal. fuel tank
  • E-Z Drive Elite: Computer-balanced driveshaft, Safe-T-Plus steering stabilizer, Koni FSD shocks, variable-rate front and rear jounce bumpers, heavy-duty front and rear stabilizer bars, 22.5 in. Michelin tires
  • TuffShell vacuum-bond laminated floor
  • TuffShell vacuum-bond laminated sidewalls
  • One-piece, seamless, crowned fiberglass roof; TuffShell vacuum-bond laminated roof
  • Bead-foam insulation (R-24 max roof, R-9 max floor, R-8 max walls)
  • 15,000-BTU A/C unit with heat pump and second 13,500-BTU A/C unit
  • 5,500-watt generator with auto-gen start
  • 1,200-watt inverter
  • 50-amp electrical service
  • 10 gal. gas/electric water heater
  • Suburban tankless water heater
  • 200W solar panel with dual controller
  • (2) 6V AGM (220Ah) house batteries on slideout tray

Full specifications

AC BTU28500 btu
Available BedsKing
Awning Info20' Electric with LED Lights
Axle Weight Front9000 lbs
Axle Weight Rear15500 lbs
Black Water Capacity72 gals
ChassisFord F53
Cooktop Burners3
Electrical Service50 amp
Engine7.3L V8
Ext Height12 ft 10 in
Ext Width8 ft 5 in
Fresh Water Capacity72 gals
Fuel Capacity80 gals
Fuel TypeGas
Furnace BTU60000 btu
GVWR24000 lbs
Grey Water Capacity72 gals
Gross Combined Weight30000 lbs
Hitch Weight5000 lbs
Horsepower335 hp
Int Height7 ft
LP Tank Capacity16.5 gals
Length38 ft 10 in
Number of Awnings1 ft
Refrigerator TypeResidential
Shower Size30" x 36"
Shower TypeStandard
Sleeps5
Slides3
Solar Wattage200 watts
TV InfoLR 50" LED HD Smart TV on Lift, BR LED HD Smart TV, Ext. LED HD Smart TV
Tire Size22.5"
Torque468 ft-lb
Washer/Dryer AvailableYes
Water Heater TypeTankless
Wheelbase252 in

Get more info

2027 Vision XL 36C
