Unit features & options

• Handmade 2” x 2” - 16” (or less) on center sidewalls with individually fastened custom “L” brackets combined with 3M® Silaprene adhesives for a stronger frame without welding or lamination (475)
• “True” High Gloss Classic Gelcoat on all exteriors - the best of the best in fiberglass. Don’t accept “hi-gloss fiberglass” or “gel-coated” sidewalls - only True gelcoat stands the test of time
• 3M® Silaprene Bonded Sidewalls – resilient, grows stronger with age. Also has outstanding resistance to UV, heat, cold, moisture, oils, gasoline, highway chemicals, and creates a bond that cannot
• Sidewalls are bolted to the floor with 5/16" x 6-1/2" carriage bolts at each outrigger
• Glued R-7 fiberglass insulation expanded to its full capacity within the sidewall frame
• Slide rooms insulated on all five sides
• 3” Aluminum frame floor with in-floor heat ducting and radius “L” brackets combined with 3M® Silaprene adhesives.
• 5/8” Tongue and groove plywood floor is attached to the aluminum frame with Silaprene and screwed every 6”.
• Fully enclosed 4’ x 8’ ABS removable panels for easier access into the underbelly. We use wood stringers to attach with no holes in the frame.
• Triple layer insulation enhances the protective values of plywood, vinyl, carpet, carpet pads, tank heaters, etc.
• 12 Volt tank heaters on all tanks.
• Radiant shield insulation – 97% reflectivity, 3% emission.
• Water lines are protected inside the floor and away from exterior walls
• Full length 3/8” wood roof decking for a full walk-on roof
• Triple layer insulation
• Aluminum Truss Rafters on 16” centers with 8” wide circular air duct. Circular ducting combined with our high performance (bigger compressor) air conditioner gives Cedar Creek a 30% increase in air co
• Optional second Whisper Quiet roof mount air conditioner (Bedroom)
• Two ply – Tuff Ply rubber roof membrane
• Roof is bolted to sidewall with 5/16” x 3-1/2” carriage bolts
• Radiant shield insulation extends around to the bottom of the front cap – R Value 40, 97% reflectivity, 3% emission
• Attic Vent
• Dexter® axles/brakes/suspension performance package
• Dexter® E-Z Flex® rubber equalization system with bronze bushings and six greased zerks per side
• Dexter® E-Z Lube® hubs
